Starting the process, guitar number 1

Page 5 / 13
  RSS

mattbeels
(@mattbeels)
Customer
Luthier
Rep Points: 13313
Joined:6 months ago
Posts: 836
30/12/2020 12:11 pm

@peebee

The practicecaster looks really good.
I like how you took the belly carve into the top bout.

Any more progress?

What kind of bandsaw do you have?

Pratice on scrap...


Deej, tv1, Boo and 2 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
30/12/2020 6:36 pm

Thanks, no more progress to report, although I did get a Bailey kit and a Bagpress fret slotting jig from Santa, no excuses now.

Bandsaw is a Record BS300

Give up the news folks, it’s liberating!


Deej, tv1, Russ and 3 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
04/01/2021 12:05 pm

Slight alteration, I have changed the pick ups to Humbuckers as these came in the Bailey kit. Trial fit of components on the drawing....all seems to fit.

2nd build will be P90s.

604E5987 5BB5 41A2 B157 D72AB79EAC65

Give up the news folks, it’s liberating!


Deej, Boo, tv1 and 3 people liked
ReplyReplyQuote
mattbeels
(@mattbeels)
Customer
Luthier
Rep Points: 13313
Joined:6 months ago
Posts: 836
04/01/2021 5:21 pm

@peebee

I meant to ask you, how do you like that saw? I‘m in the market for a new one and Record Power seems like a good choice.

How is the quality/stability? Overall impression?

Thanks a lot!

Pratice on scrap...


Deej, tv1, Boo and 1 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
04/01/2021 6:57 pm

So far the saw is a treat, bloody heavy though!

Seems easy to set up and the blades are easy to change, I would say it’s the best quality tool I own.

There are also some good support videos on YouTube from Record Power re how to set up etc.

Give up the news folks, it’s liberating!


Deej, Boo, mattbeels and 2 people liked
ReplyReplyQuote
tv1
 tv1
(@tv101)
Luthier
Rep Points: 16760
Joined:11 months ago
Posts: 1962
04/01/2021 9:35 pm

So far the saw is a treat, bloody heavy though!

Can you put it on a wheeled stand @peebee?

Ikm guessing that you mention the weight because you’re having to move it around.  A wheeled stand would make that easier.

Online guitar making courses – guitarmaking.co.uk


Deej, Boo, mattbeels and 1 people liked
ReplyReplyQuote
mattbeels
(@mattbeels)
Customer
Luthier
Rep Points: 13313
Joined:6 months ago
Posts: 836
05/01/2021 12:03 am

@peebee

Sounds great, thanks for letting me know!

Pratice on scrap...


Deej, tv1, Boo and 1 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
05/01/2021 9:17 am

TV it has wheels on oneside of the bottom frame so you can tip it up and pull it. I believe you can buy a wheeled frame for it. However, I rarely have to move it to be honest so its fine but just getting where I wanted it in the first place was hard work. I have since bought a large sack barrow, for moving large plants actually, but I might be able to use this if I need to move it again.

My garage is further complicated in that it does not have a smooth floor, but a rippled concrete floor, one day I might level it. (First world problems eh!)

Give up the news folks, it’s liberating!


Deej, tv1, Boo and 3 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
05/01/2021 3:46 pm

Had to play IT support today for my lads first day back at school, remote learning and all that, so not much done. But sat in the kitchen and made a humbucker template from mdf, so not a total loss.

Cleaned up thoroughly before the boss came home!

Give up the news folks, it’s liberating!


Deej, tv1, Boo and 3 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
06/01/2021 10:54 am

Neck taper template making today and still IT support for home schooling!

9F466C84 E230 4169 92E2 FE71C2685919



Give up the news folks, it’s liberating!


Deej, tv1, mattbeels and 3 people liked
ReplyReplyQuote
Boo
 Boo
(@boo)
Customer
Luthier
Rep Points: 19114
Joined:2 years ago
Posts: 2271
06/01/2021 11:09 am

Neck taper template making today

Ah the dreaded neck taper jig. Let us know how you get on with it. That’s some fancy measuring equipment you have there @peebee What you designing, a suspension bridge? 😁

I’m joking, you are doing great man, it all looks good. 🤘😜🤘

Online guitar making courses – guitarmaking.co.uk


Deej, tv1, mattbeels and 1 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
06/01/2021 2:23 pm

Well got there, this is the most difficult jig of the lot!

43mm at the nut then I measured 56mm at the last fret. This is where I strayed from the on line course, Mark says 480mm between them on his video, but for me at the 22nd fret using a 25inch scale the distance between the nut at 43mm and the 56mm 22nd fret I made 457mm, from the scale length calculator it should be 456.81mm, so close enough.

I also have a Bailey pre made fret board and this fits my template almost perfectly so I’m happy that it must be close enough for Jazz as they say.

Marking the centre line was a laugh but got there in the end.

0383ADB2 B012 48D3 8EE9 A55DAF1A43D1

Give up the news folks, it’s liberating!


Deej, tv1, mattbeels and 3 people liked
ReplyReplyQuote
Robin
(@robin)
Luthier
Rep Points: 7560
Joined:9 months ago
Posts: 540
06/01/2021 2:49 pm

Hi Peebee

Mark says 480mm between them on his video, but for me at the 22nd fret using a 25inch scale the distance between the nut at 43mm and the 56mm 22nd fret I made 457mm, from the scale length calculator it should be 456.81mm, so close enough.

The fretboard in my Bailey kit was a 24 fret, even though I cut back to only use 22 of them. I think Mark's 480mm is based on the 24 fret length. To be honest, you'd need very good eyes to spot the difference in the tapers. As you say, good enough for jazz.


Deej, tv1, mattbeels and 2 people liked
ReplyReplyQuote
Peebee
(@peebee)
Luthier
Rep Points: 1406
Joined:5 months ago
Posts: 144
06/01/2021 5:16 pm

@Robin, I think you’re right as the distance to the 24th fret from the nut is 476.252mm so close to 480mm.

My kit is a 22 fret,  so 457mm, just checked again as doubt briefly crept in.

Its worth noting that there is a difference though and it may / will affect the neck pocket size, so follow this part of the on-line course with a note of caution I would suggest.

Give up the news folks, it’s liberating!


Deej, tv1, mattbeels and 3 people liked
ReplyReplyQuote
Robin
(@robin)
Luthier
Rep Points: 7560
Joined:9 months ago
Posts: 540
06/01/2021 6:31 pm

Hi Peebee

Its worth noting that there is a difference though and it may / will affect the neck pocket size, so follow this part of the on-line course with a note of caution I would suggest.

My heel was a bit loose in the pocket of my first build and I had to put a little shim in when I glued it. Most probably because of my router inexperience. I'm being extra careful this time and left the heel about 0.5mm too wide and I'll take it down to size when I'm fitting it.


Deej, tv1, mattbeels and 2 people liked
ReplyReplyQuote
