Building a guitar for my thesis for school.

Page 5 / 6
  RSS

tv1
 tv1
(@tv101)
Luthier
Rep Points: 16759
Joined:11 months ago
Posts: 1962
30/03/2021 8:04 pm

and now i have 3 weeks off

Isn’t that study time, or revision time, or something??

😋 😋

Surely it can’t just be 3 weeks for you to do fun stuff ....





Be great to see the guitar progress - are you aiming to get it all done in the 3 weeks?

Online guitar making courses – guitarmaking.co.uk


Deej, mattbeels, Robin and 3 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
30/03/2021 8:10 pm

@tv1

hi, yes i have 3 weeks off. But i have some small task for school wich i spread throughout the 3 weeks. In the morning i do some tasks and in the afternoon i have time to build the guitar. I have all my parts ready, so yes i am planning on finishing it in these 3 weeks!



Take care

Louis


Deej, Bill Flude, tv1 and 4 people liked
ReplyReplyQuote
Boo
 Boo
(@boo)
Customer
Luthier
Rep Points: 19113
Joined:2 years ago
Posts: 2271
30/03/2021 8:20 pm

In the morning i do some tasks and in the afternoon i have time to build the guitar. I have all my parts ready, so yes i am planning on finishing it in these 3 weeks!

@louis-kerckhove Good for you Louis, get cracking. 👍

Online guitar making courses – guitarmaking.co.uk


Deej, Bill Flude, tv1 and 4 people liked
ReplyReplyQuote
Clinton
(@clinton)
Customer
Luthier
Rep Points: 2912
Joined:11 months ago
Posts: 443
31/03/2021 5:33 am

Home stretch @louis-kerkove. Yup Boo is right in the fretwire. Really do not want to mess around with inappropriate radius in fretwire. It is nerve wracking as it is already. 9.5 is too extreme for 12 but can be manually bent if you wish. May not be worth the hassle if doing so. Syick with the plan. You are almost there. Keep it coming.


Deej, Bill Flude, Boo and 5 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
01/04/2021 7:11 pm

Update:

Drilled the holes for the strap locks and tuners today. I also drilled a hole on the side of the body for the guitar cable, i made sure that the hole is far enough from my leg so that the cable doesn't interrupt the playing. I also glued the fretboard onto the neck, now i will let it dry overnight (i made sure to use enough clamps). Tommorow i will put the frets in and start making my own custom scratchplate. Here are some pictures of

the progress so far:

20210401 153358
20210401 145421
20210401 104504
20210401 105042
20210401 101543

 Louis




Rocknroller912, Deej, Bill Flude and 5 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
07/04/2021 4:31 pm

Update:

Did the fretjob and i am cutting the scratchplate now (pictures coming soon). I have a question regarding electronics. I am using a humbucker, 1tone, 1 volume configuration but i want to add 2 caps instead of one. I also have a switch to choose between the 2 caps so that i can show my teachers the range of frequencies that can get cut out on both caps. Is it safe to put 2 caps in this configuration? I have a shematic to make things clearer.

SCAN0045

Louis


mattbeels, tv1, Deej and 4 people liked
ReplyReplyQuote
rockpile99
(@rockpile99)
Semi Professional
Rep Points: 469
Joined:7 months ago
Posts: 68
07/04/2021 5:16 pm

Hi Louis

It's been nearly 30 years since I did my electronic engineering HND but your circuit diagram makes sense. I've never seen a guitar use capacitors that large though - do you really mean 27 and 33 Millifarads (mF)? More common values would be 0.1, 22, 33, or 47 Microfarads (uF) depending on the type of pickup and the preferred sound.

If you're wanting to demonstrate how the capacitor effects the tone for your thesis then have you considered soldering some wire and crocodile clips to the tone pot? You could then demonstrate a much wider range of caps.

What taper are you using on the tone pot - linear or audio? With linear (the standard wisdom for tone pots) your ears don't really notice a big change until you've turned the pot a long way. With audio taper you get a more noticeable change for a small amount of movement.

Thankfully solder is easy to remove so I'd say experiment with a variety of caps and pots until you find something that sounds good to you (that's the important bit - not the values used).

Other tips for soldering; tin the wire ends first, rub the pot bodies with sandpaper, melt some solder onto the pot before attempting to join any wires, and don't blow on joints to cool them down. The less time the pots are exposed to heat - the less chance of damaging anything.

Guitar making is the art and science of turning expensive wood into sawdust.


mattbeels, tv1, Deej and 4 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
07/04/2021 5:38 pm

Hi Louis

It's been nearly 30 years since I did my electronic engineering HND but your circuit diagram makes sense. I've never seen a guitar use capacitors that large though - do you really mean 27 and 33 Millifarads (mF)? More common values would be 0.1, 22, 33, or 47 Microfarads (uF) depending on the type of pickup and the preferred sound.

If you're wanting to demonstrate how the capacitor effects the tone for your thesis then have you considered soldering some wire and crocodile clips to the tone pot? You could then demonstrate a much wider range of caps.

What taper are you using on the tone pot - linear or audio? With linear (the standard wisdom for tone pots) your ears don't really notice a big change until you've turned the pot a long way. With audio taper you get a more noticeable change for a small amount of movement.

Thankfully solder is easy to remove so I'd say experiment with a variety of caps and pots until you find something that sounds good to you (that's the important bit - not the values used).

Other tips for soldering; tin the wire ends first, rub the pot bodies with sandpaper, melt some solder onto the pot before attempting to join any wires, and don't blow on joints to cool them down. The less time the pots are exposed to heat - the less chance of damaging anything.

@rockpile99 Thanks you so much for the in depth explenation, i will be using the tips u recommended!

I was reffering to MicroFarads, I asked my electricity teacher for a couple caps to experiment with and he gave them. My tonepot is a audiotaper and my volume just a regular lineair pot. Thanks again, really helpfull tips!


mattbeels, tv1, Deej and 3 people liked
ReplyReplyQuote
Deej
 Deej
(@deej)
Luthier
Rep Points: 10298
Joined:2 years ago
Posts: 834
07/04/2021 9:19 pm

I think I’ll leave this Q to more qualified electrical knowing members..the thought always gives me shivers when I think of soldering!

I have too many guitars...said no one in the world..ever!


mattbeels, Louis.kerckhove, Russ and 2 people liked
ReplyReplyQuote
tv1
 tv1
(@tv101)
Luthier
Rep Points: 16759
Joined:11 months ago
Posts: 1962
07/04/2021 9:29 pm

There are some great options for alternative tone wirings out there Louis, and some websites devoted just to them!

Take some time looking through articles on Premier Guitar ...

https://www.premierguitar.com/diy/mod-garage/mod-garage-deep-diving-into-treble-bleed-networks

Somewhere, I've got a link to a guy who built an off-guitar switching board, so he could try out different cap values on a test set-up without having to re-solder his guitar each time.  I'l try to dig that out tomorrow.

Top tip for soldering - get yourself a decent soldering station if you're going to be doing much soldering.  A variable-temperature iron with that lets you change the tips depending on what you're soldering.

Also, whilst I think of it - I've fitted a varitone control to a couple of guitars.  Gibson used it on a couple of models, including the Blueshawk.

http://www.bigdguitars.com/products/big-d-varitone-switch



Online guitar making courses – guitarmaking.co.uk


mattbeels, Louis.kerckhove, Russ and 2 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
14/04/2021 5:05 pm

PROJECT IS FINISHED!



Hi guys, my guitar project is finished, i still have to make a plate to cover the trussrod at the headstock but the guitar is ready and she plays fantastic. here are some pictures, i will try to upload a demo of the sound when i have some more time. I know it may not be the best build someone has ever done, but i am proud i have a working guitar that i will enjoy and love for the rest of my life.

20210414 144536
20210414 174259
20210414 174159
20210414 174203
20210414 174255
20210414 174147

Clinton, tv1, Boo and 4 people liked
ReplyReplyQuote
jamesbisset
(@jamesbisset)
Technician
Rep Points: 669
Joined:11 months ago
Posts: 154
14/04/2021 5:17 pm

That’s amazing! Well done!

Jack of all trades and master of my own destiny. It’s only a small destiny.


tv1, Boo, Russ and 2 people liked
ReplyReplyQuote
Rocknroller912
(@rocknroller912)
Luthier
Rep Points: 3093
Joined:8 months ago
Posts: 458
14/04/2021 5:31 pm

Well done Louis it looks very good, you should get top marks for your thesis.

Don’t call us we’ll call you


tv1, Boo, Russ and 2 people liked
ReplyReplyQuote
Louis.kerckhove
(@louis-kerckhove)
Technician
Rep Points: 530
Joined:6 months ago
Posts: 64
14/04/2021 5:35 pm

you should get top marks for your thesis.

@Rocknroller912

Thanks man! I hope so, we will see


tv1, Boo, Russ and 2 people liked
ReplyReplyQuote
mattbeels
(@mattbeels)
Customer
Luthier
Rep Points: 13313
Joined:6 months ago
Posts: 836
14/04/2021 6:39 pm

Congratulations and great job @louis-kerckhove!

I see that you modded the cutaway for better fret access, nice move. 😉

Now go shred those high notes and make @tv101 squeal like a pig, Soo Wee! 😆

Pratice on scrap...


Louis.kerckhove, tv1, Boo and 1 people liked
ReplyReplyQuote
